Performance & Operating Details

• Operating Weight: 10,900 lb

• Fuel Type: Diesel

• Engine Power: 48.3 hp

• Fuel Tank Capacity: 20.1 gallons

• Max Travel Speed: 2.9 mph

Dimensions

• Overall Height: 8 ft 5 in

• Overall Width: 6 ft 3 in

• Overall Length: 17 ft 7 in

• Ground Clearance: 1 ft 3 in

• Tail Swing: Zero Tail Swing

Digging & Lifting

• Bucket: 24" Dig bucket with teeth

• Max Dig Depth: 11 ft 7 in

• Max Dump Height: 13 ft 1 in

• Max Reach at Ground Level: 19 ft 2 in

• Rated Operating Capacity (est.): ~2,700 lb (varies based on lifting point and load position)

• Bucket Breakout Force: 8,540 lb

• Dipper (Arm) Tearout Force: 4,945 lb

Optional 42" Tilt Bucket Attachment

• Daily Rental: $80

• Weekly Rental: $250

• Monthly Rental: $600
