Engine & Performance

Engine: 74 hp (55 kW) JCB EcoMAX TCAE-55 turbo diesel
Emissions: Tier 4 Final; no diesel particulate filter or exhaust aftertreatment required
Operating Weight: 11,003 lb (4,991 kg)
Rated Operating Capacity: 2,723 lb (1,235 kg) at 35% of tipping load
Static Tipping Load: Approximately 7,780 lb (3,529 kg)
Lift Path: Vertical
Travel Speed: Up to 7.8 mph (12.5 km/h) with two-speed transmission

Dimensions & Lift

Hinge Pin Height: 10 ft 5 in (125 in)
Overall Machine Width: Approximately 78 in with standard tracks
Standard Track Width: 17.7 in (450 mm)
Loader Lift Capacity: 5,807 lb (2,634 kgf)
Dump Height: Approximately 7 ft 10 in (2.38 m)

Hydraulics

Standard Auxiliary Hydraulic Flow: 24 gpm (91 L/min)
Optional High-Flow Hydraulics: Up to 33 gpm (125 L/min)
